| Specification | Description |
|---|---|
| Clamp Force: | 2200 US Ton |
| Shot Size: | 540.5 Oz/165 mm |
| Platen Size: | 102.4" x 94.5" |
| Tie Bar Spacing: | 75.4" x 61" |
| Max Daylight: | 134.3" |
| Min/Max Mold Ht: | 29.9" - 73.2" |
| Clamp Stroke: | 104.3 |
| Ejector Stroke: | 5.7" |
| Voltage: | 460 |
| Dimensions: | 48L' x 15.4'W x 12.5'H |
| Weight: | 375,000 lbs |
| Location: | Northeast |
| Currently under power |
