| Specification | Description |
|---|---|
| Clamp Force: | 280 US Tons |
| Shot Size: | 20 Oz |
| Platen Size: | 39" x 39" |
| Mold mold size: | 24" x 32" |
| Max Daylight: | 35" |
| Min/Max Mold Ht: | 11.5""/24.5" |
| Maximum Mold Space: | 24"D x 36"W |
| Centerline of Injection | 6.5"Min - 11"Max |
| Clamp Stroke: | 23.5" |
| Ejector Stroke: | 3.5" (penetration ?") |
| Ejector force: | 8.9 US Tons |
| Rotary table dia: | 77" |
| Voltage: | 460 |
| Dimensions: | 181" x 85"W x 133"'H |
| Weight: | 46,000 lbs |
